SunWize SWPB-65-MC4 Solar Module
Heavy-duty, industrial 65W, nominal 12V (36-cell) or 24V (72-cell) solar module featuring a UL 1703 certification and pre-installed MC4 Cables.
This solar module (SunWize Part# 270173) is a replacement for the following 12V SolarTech Power modules: SPM065P-N (SunWize Part# 018654) and the following 24V SolarTech Power modules: SPM045P-WP-N (SunWize Part# 018647), SPM055P-WP-N (SunWize Part# 018651), SPM065P-WP-N (SunWize Part# 018655).
From: $254.24 – $262.53
Features
- 65W / 12V or 24V / UL 1703 Certified
- 5-Year product workmanship warranty
- Anodized aluminum tubular frame for durability
- Two bypass diodes protect against hot-spot damage
- Impact-resistant glass allows max light transmission
- Junction Box with (4) ½” conduit knockouts and installed MC4 cable
- Replacement for other 12V 65W MC4 modules, such as SolarTech Power SPM065P-N (SunWize Part# 018654) and other 24V MC4 modules, such as SolarTech Power SPM045P-WP-N (SunWize Part# 018647), SPM055P-WP-N (SunWize Part# 018651), SPM065P-WP-N (SunWize Part# 018655).
Product Data
SunWize SWPB-65-MC4 Solar Module
The SWPB-65-MC4 is a 65W solar module with UL 1704 rating and MC4 cables pre-installed, available in nominal 12V or 24V
These modules are perfect for general industrial use in a wide variety of applications such as telecommunications, security, traffic signage, environmental monitoring, and others. What’s more, this is a direct replacement for other 65 Watt modules such as the SolarTech Power 12V SPM065P-N and the 24V SPM045P-WP-N, SPM055P-WP-N, and SPM065P-WP-N. The SWPB-65-MC4 can charge 12 Volt, 24 volt, or 48 Volt batteries when wired into one, two, or four solar modules. UL 1703 certified.
These modules feature impact-resistant glass and heavy-duty aluminum frames. It also has three sets of mounting holes, making it a great choice for flexible mounting options. Because of the robust design and features, this module is an excellent choice for off-grid solar power applications in harsh locations. Additionally, it features single crystalline solar cells bonded to white Tedlar backing ensuring a long life in severe environmental conditions. This solar module (12V SunWize Part# 270173, 24V SunWize Poart# 270409) is an excellent alternative and replacement for the following 12V/24V solar modules:
- SolarTech Power – SPM065P-N (SunWize Part# 018654)
- SolarTech Power – SPM045P-WP-N (SunWize Part# 018647)
- SolarTech Power – SPM055P-WP-N (SunWize Part# 018651)
- SolarTech Power – SPM065P-WP-N (SunWize Part# 018655)
- Ameresco Solar – BSP65-12
- SolarLand – SLP065S-12U
Looking for more information related to Solar Modules? Check out our Tech-Notes on Module Shading and Temperature Compensation. Looking for info on hazardous location ratings for solar modules? Click Here!
